Maybe you can help me. I have the same issue. I need to write a LabWindows application using NI IVI drivers, but I have no luck since when I open NI MAX NO DRIVERS are available. That is: I open MAX to create a New Logical Name, but once I’ve created the Logical Name, no Drivers are available and the “Go To” buttom remains disaibled.

1. Ivi Driver Labview
2. Ivi Foundation Drivers

I’ve run a quite new software installation on a clean machine (PC, x86,32 Bits, WIN7) following these steps:. I’ve installed NIDAQmx 9.7.5 with its updates. I’ve downloaded and installed the NI IVI Compliance Package 4.6 - Windows 8/7/Vista/XP/Server 2008/Server 2003 R2 32-bit Reboot PC. I’ve installed LabWindows CVI 2013 when installation proccess was almost done, I was asked to installed NI Device Drivers, as I hadn’t them available I chose to install them later. I’ve installed Labwindows CVI 2013 available updates. Reboot PC.

Finally, i’ve installed NI Device Drivers. Am I missing something? What can be wrong?

Thanks in advance for your atention. I'm having the same problem. Where do I find the IVI-C drivers to install? I've tried the NI website, IVI Foundation (Class drivers just links me back to ni.com and the page that says to download the NI IVI Compliance Package). Under IVI Drivers in the menu bar in MAX, I can see Simulation Driver Software Modules and Simulation Driver Sessions. But, the folders containing Instrument Driver Software Modules and Driver Sessions are empty.

Ivi Driver Labview

I've installed IVI drivers, NI-VISA, and Agilent VISA on my computer. I have specific hardware drivers installed on my computer (e.g. For Agilent equipment). I was able to install and access them through LabVIEW when laying out my schematic. But, I don't see them in the MAX. They are located in folders in my C: Program Files (x86) National Instruments LabVIEW 2014 instr.lib directory. The drivers themselves are composed of.lvproj and.lvlib files.

The instr.lib directory also contains a lot of 'Template - XYZ' folders (where XYZ are componets like DC Power or DMM). Aren't these the files that are supposed to be automatically detected by the MAX as drivers? I've also tried installing IVI-C drivers directly liike the NISCOPE but installation of it resulted in an incompatibility error.

IVI Driver Help Edition Date: August 2011 Part Number: 370430H-01 » The IVI Compliance Package supports several IVI driver classes. You can develop hardware independent test programs with these driver classes. The setup program installs the files you need to use the class drivers with LabWindows/CVI and LabVIEW. Note Refer to the following help files for more information about which IVI driver classes the IVI Compliance Package supports. Download karafun 2.5.2 build 5 (free for mac).

LabWindows/CVI—. LabVIEW— LabWindows/CVI For LabWindows/CVI, an IVI class driver consists of the following files:. The class driver program, which consists of a.dll file and import library (.lib) files for various compilers. The class driver includes file (.h), which contains the function declarations and constant definitions for the class. The class driver function panel file (.fp), which defines the function tree, the function panels, and the help text.

The.sub file, which documents attributes and their possible values. A Windows HTML help file (.chm), which contains documentation for the LabWindows/CVI class driver. LabVIEW For LabVIEW, an IVI class driver consists of the following files:. The class driver VIs, which are in a.llb file. The VIs link to a.dll file.

Ivi Foundation Drivers

The.rc file, which documents properties and their possible values. A set of.mnu files, which documents the hierarchy of VIs for the class driver. A Windows HTML help file (.chm), which contains documentation for the LabVIEW class driver. Refer to for more information about class drivers.
